DNAKE 290M-S8

The DNAKE 290M-S8 is designed for upgrading existing 2- wire intercom system to IP system in apartment buildings. It can be connected to some old 2-wire buildings with no cable replacement. It provides multiple functions, including audio and video intercom, emergency call, security alarm and lift control, etc.


Features

  • 7-inch Indoor Monitor (2-wire Version)

    •7” capacitive touch screen, 800 x 480
    •Video monitoring of DNAKE IP intercoms & IPC
    •HD quality audio and video communication
    •8-ch alarm input, 1xRS485
    • 48V DC power supply
    •User friendly user interface, easy to understand
    •Quick installation and remote management via web interface

Specifications

  • System

  • Linux

  • RAM

  • 64MB

  • ROM

  • 128MB

  • Front Panel

  • Plastic

  • Power Supply

  • Two wire supply

  • Standby Power

  • 1.5W

  • Rated Power

  • 9W

  • Installation

  • Surface mounting

  • Dimension

  • 221.4 x 151.4 x 16.5mm

  • Working Temperature

  • -10℃ - +55℃

  • Storage Temperature

  • -10℃ - +60℃

  • Working Humidity

  • 10%-90% (non-condensing)

  • Display

  • 7-inch TFT LCD

  • Screen

  • Capacitive touch screen

  • Resolution

  • 800 x 480

  • Audio Codec

  • G.711

  • Video Codec

  • H.264

  • Protocol

  • SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP

  • Ethernet Port

  • 2-wire Port

  • RS485 Port

  • 1

  • Power Output

  • 1 (12V/100mA)

  • Doorbell Input

  • 8 (Use any alarm input port)

  • Alarm Input

  • 8
